Thermalright AXP-200 Muscle

Fine cooler at a good price that fits perfectly in a smaller system, for example a HTPC.

The cooling of such a small cooler is terrific, and can be used for cooling of all CPU types.

This fine cooler from Thermalright can easily be used in a smaller system. If you have to fit a lot into a smaller cabinet, this cooler is the obvious choise, bacause it is only 73mm tall including the fan.

Thermalright AXP-200 Muscle also gives you the opportunity to install all fans with 120mm mounting holes. The package contains a special 150mm x 140mm fan with 120mm mountingholes.

Specifications:
Heatsink Specifications:
Dimension: L153 mm x W140 mm x H60 mm
Weight: 475g
Heat pipes: 6mm heatpipe x 6 units
Fin: T = 0.5 mm ; Gap = 2.0 mm
Fin Pcs: 1+17+17+5+9 = 49 pcs
Copper Base: C1100 Pure copper nickel plated
Motherboard to Fin: 22+8 = 30 mm & 34+8=42mm

Compatibility:
Intel Socket 1366, 1156, 1155, 1151, 1150, 775
AMD Socket AM3, AM2, AM2+, FM1, FM2, FM2+

TY-14013 FAN Spec
Dimension: L150 mm x H140 mm x W13 mm
Weight: 90g
Rated Speed: 700~1300RPM±15%
Noise Level: 30.6dBA(Max.)
Air Flow: 64.52CFM

Vårt artikelnr:
00TR122
